MH7200 |
|
 |
产品信息 |
|
| |
Out Power 输出功率(8Ω):2×800W
Out Power 输出功率(4Ω):2×1300W
Out Power 输出功率(2Ω):2×1900W
Out Power (BRIDGE) 桥接方式(8Ω):2600W
Out Power (BRIDGE) 桥接方式(4Ω):3800W
Output Circuit Type 线路类型:Class H
Input Impedance 输入阻抗:20KΩ
Frequency Response 频率响应:20Hz ~ 20KHz
THD 总谐波失真 20Hz ~ 20KHz(8Ω):0.0005
Slew Rate 转换速度:80V/usec
Hum and Noise 信噪比:103dB
Damp Modulus 阻尼系数(8Ω): ＞500
Radiator 散热方式:High/Low Automatism Corlrol
Suteguard 保护方式:DC Safeguard/out Overloading/Chancroid Sgartup/Boot-Strap Short Test
N Weight 净重 / G Weight 毛重(Kg):27 / 29.5
Dimension 尺寸(mm):482×443.5×88.8
Power Range 电压:(115V/230V) Can offer different voltage according client's requirement |
