MA400 |
|
 |
产品信息 |
|
| |
Out Power 输出功率(8Ω):2×400W
Out Power 输出功率(4Ω):2×700W
Out Power 输出功率(2Ω):2×1000W
Out Power (BRIDGE) 桥接方式(8Ω):1250W
Out Power (BRIDGE) 桥接方式(4Ω):1700W
Output Circuit Type 线路类型:Class AB
Input Impedance 输入阻抗:20KΩ
Frequency Response 频率响应:5Hz ~ 50KHz
THD 总谐波失真 20Hz ~ 20KHz(8Ω):0.0005
Slew Rate 转换速度:40V/usec
Hum and Noise 信噪比:103dB
Damp Modulus 阻尼系数(8Ω): ＞400
Radiator 散热方式:High/Low Automatism Corlrol
Suteguard 保护方式:DC Safeguard/out Overloading/Chancroid Sgartup/Boot-Strap Short Test
N Weight净重 / G Weight 毛重(Kg):22.5 / 24
Dimension 尺寸(mm):482×440×88.8
Power Range 电压:(115V/230V) Can offer different voltage according client's requirement
|
